Refrigeration Selected for 50 °C.

Condensing units, evaporators and compressor racks from established manufacturers, selected for the load and supplied with condensers sized for a Gulf summer.

Enquire Now Downloads

Selected for the Heat.

We supply the plant side of a cold room or process-cooling job: the condensing unit or rack, the matched evaporator, and the condensers and controls between them.

The equipment comes from established manufacturers, with reciprocating, scroll or screw compressors and components with full traceability. Technics selects it for the duty and supports it from the UAE.

The load, the room temperature and the ambient are all that a matched selection needs.

Technician servicing rooftop refrigeration equipment Compressor rack installation

Why Specify It

Equipment selected for the climate, supplied and supported locally.

1 to 134

kW cooling, condensing units

Single- and two-stage air-cooled units across the medium- and low-temperature range for cold rooms and process loads.

20 to 700

kW cooling, compressor racks

Reciprocating and screw racks with two to six compressors for large storage, processing and industrial refrigeration.

50 °C

Ambient design

Condensers sized and fans selected for Gulf summer ambient so capacity is maintained when it matters.

Established components

Compressors, controls, valves and fans from recognised manufacturers with full traceability on every unit.

Corrosion-resistant construction

Coated coils and powder-coated housings for coastal and industrial sites.

Factory tested

Every unit is pressure-tested, evacuated and leak-tested at the factory before dispatch. Test records come with the unit.

Matched systems

Condensing unit, evaporator, controls and cold-room doors and panels supplied together where the project needs a complete package.

Lower-GWP refrigerants

Standard HFC and lower-GWP blends, with selections adjusted for the refrigerant specified.

Local support

Spares, service and technical support from the UAE, not from a distributor overseas.

Product Categories

Four categories cover most cold-storage and process jobs.

Air-cooled condensing unit with compressor and receiver

Air-cooled condensing units

Housed units with compressor, condenser coil, fans, receiver and controls for cold rooms and small process loads.

Capacity 1 to 134 kW cooling
Stages Single and two-stage
Compressors Reciprocating or scroll
Duty Medium and low temperature
Ceiling-mounted two-fan cold-room evaporator

Evaporators and air coolers

Ceiling- or wall-mounted unit coolers matched to the condensing unit and the room.

Duty Chill, freeze and blast applications
Defrost Electric or hot-gas
Coils Copper tube, aluminium fin; coated fins on request
Fans EC or AC axial
Three-compressor refrigeration rack

Compressor racks

Multi-compressor racks on an open welded frame for large storage and industrial loads.

Capacity 20 to 700 kW cooling
Compressors 2 to 6, reciprocating or screw
Includes Receiver, filters, sight glass, safety valve, pressure switches
Condensers Remote air-cooled, ours or existing
Insulated cold-room entrance and heat exchanger

Heat exchangers and cold-room hardware

Air-cooled condensers, plate and shell exchangers, insulated doors and sandwich panels.

Condensers Remote air-cooled, V and horizontal
Exchangers Brazed plate, shell and tube
Doors Hinged and sliding insulated doors
Panels PU/PIR insulated sandwich panels

Where It Is Specified

From one walk-in cold room to a multi-rack distribution centre.

Cold rooms and cold stores

Chill and freezer rooms for food service, distribution and pharmacy.

Condensing unitsEvaporators

Food processing

Process cooling, blast chilling and freezing with hot-gas defrost.

RacksBlast evaporators

Supermarkets and retail

Central racks serving display cases and back-of-house rooms.

RacksControls

Hospitality kitchens

Compact condensing units for kitchen cold rooms, often on the roof.

Condensing units

Healthcare and pharma

Temperature-controlled storage with monitoring and alarm outputs.

Condensing unitsMonitoring

Industrial and process

Chilled water, brine and glycol duties for production lines.

RacksHeat exchangers

From Specification to Delivery

Select, confirm, supply, support.

  1. Select

    Load, room or process temperature and ambient set the compressor, coil and fan selection.

    • Load calculation
    • Refrigerant and duty
    • Matched evaporator

  2. Confirm

    Selection sheets, capacities and drawings are issued for approval before the order is placed.

    • Selection sheet
    • Capacity at design ambient
    • Electrical data

  3. Supply

    Units are ordered to the approved selection, factory-tested and delivered to site with their documentation.

    • Factory test records
    • Wiring diagrams
    • Delivery to site

  4. Support

    Start-up support, spares and service from the UAE for the life of the equipment.

    • Start-up assistance
    • Spares
    • Service and technical support

Performance Data

Typical ranges for the equipment families Technics selects from, to be confirmed at selection. Full data comes with every quotation.

Parameter Value Basis
Condensing unit capacity 1 to 134 kW Cooling capacity at rated conditions
Compressor rack capacity 20 to 700 kW MT 30 to 700 kW; LT 20 to 500 kW
Compressor types Reciprocating, scroll, screw Per duty
Temperature range Medium and low temperature Room −25 °C to +10 °C typical
Ambient design Up to 50 °C Gulf summer
Refrigerants R134a, R404A, R448A/R449A, R513A; others on request Per specification
Defrost Electric or hot gas Evaporators
Controls Electronic controller, pressure switches, alarm and BMS outputs Standard
Coil protection Coated fins and housings on request Coastal / industrial
Factory tests Pressure test, evacuation, charge, leak test Every unit
Capacity figures are typical ranges for the equipment families and are confirmed for each project; a selection depends on refrigerant, evaporating and condensing temperatures and ambient. Selection sheets are issued with every quotation.

Datasheets and Documents

Sent from our engineering office on request.

Common Questions

What do you need to size a condensing unit?
The cooling load (or room size, product and throughput), the room temperature, the ambient at the unit location and the refrigerant if specified.
Do you supply the evaporator with the condensing unit?
Yes. We match the evaporator to the unit and the room so the pair is balanced at the design condition.
Which refrigerants do you use?
Standard HFCs and lower-GWP blends including R448A and R449A. Selections are adjusted for the refrigerant specified on the project.
Are units suitable for rooftop installation?
Yes. Housed units are weatherproof and fans and coils are sized for outdoor Gulf ambient. Coated coils are recommended near the coast.
What is tested before dispatch?
Every unit is nitrogen pressure-tested, evacuated and leak-tested at the factory. Test records are supplied with the unit.
Do you provide service?
Yes. Spares, service and technical support are provided from the UAE for everything we supply.
